Clean water dishwasher - Pump - Basket cm 40 x 40 - cm 50 x 52 x 71.5 h
S-PRR-UNICA40P
PROJECT SYSTEMS
S-PRR-UNICA40P
€1,551.12
€1,632.76
-5%
€1,551.12 Senza tasse
€1,892.37 Con tasse
€1,632.76 Senza tasse
Tax excluded
Clean water electronic dishwasher - Model UNICA40P - Exhaust pump - Framework basket cm 40 x 40 - Useful height door cm 28 - Temporary peristaltic dispenser of sparking - Temporary peristaltic dispenser of detergent - Size cm 50 x 52 x 71.5 h
Options
+ ACCESSORIES
PRODUCT INFORMATION | |
---|---|
Dishwasher | UNICA40P |
Appropriate | Professional use |
Dimensions | cm 50 x 52 x 71.5 h |
Packaging dimensions | cm 60 x 52 x 78 h |
Gross/net weight | Kg 35-36 |
Norma | CE |
Warranty | 12 months |
TECHNICAL DATA | |
---|---|
Production | 1000 pcs/h |
Power supply | 400V 3N+T50Hz |
Power total | 6190 W |
Resistance boiler | 6000 W |
Bath resistance | 2 x 900 W Active Dynamic Control |
Washing pump | Q = 95 lt/m - Hmax= 6 mt |
Bath capacity | 7 lt |
Capacity boiler | 6.5 lt |
Water supply | 2 Atm. 3/4 gas |
Water cycle consumption | 4 lt |
Duration | 180 " -240" Continuos mode: thermostop |
Size basket | Square 40 x 40 (optional Ø 41 cm) |
Maximum height of dishes | 280 mm |
Exhaust pipe | Ø 28 |
GENERAL FEATURES | |
---|---|
Clean water washing system, with constant volume, where the water is exchanged at each washing cycle with sparking and detergent automatically dosed in a suitable manner | |
The best results in professional washing, in terms of hygiene, performance and savings are possible only through the washing cycles offered by a clean water dishwasher | |
Washing cycle: with the water of the previous rinse that is in temperature and without residues of previous washes. The product dose required for each cycle is automatically entered through the appropriate detergent dispenser. Excessive waste and excessive concentrations of detergent cause foam and loss of the correct product cleansing action | |
The washing is carried out using fresh water at each cycle (with automatic addition) of detergent and sparkling in the right doses. Wash water never comes into contact with rinse water. With the total water exchange in the tub you can wash in succession dishes with very different dirt. Example limit: coffee cups and in the next cycle dishes where fish was consumed. All without contamination in the dishes due to the percentage of stagnant water in the tank as it happens in traditional machines | |
Drainage: this phase lasts only a few seconds but it is necessary to ensure that all the water in the circle is collected in the appropriate tank | |
Drain: finished washing, through the discharge of the water a cleaning of the tank and prepares the machine to the next final rinse | |
Risciacquo: At volume, and not in time, so to have the certainty of a perfect rinse also with little pressure. It comes at 90° with clean water coming from the appropriate boiler and correctly concentrated in the right amount of sparkling wine. The water filtered in the tank is then used for the next washing only | |
Entirely built in stainless steel 18/10 AISI 304 | |
Double wall 25 mm. | |
Temporary peristaltic dispenser of standard shiner and temporary peristaltic meter of series detergent. | |
Standard equipment 2 baskets plus 1 holders and 1 holders | |
Complete automation of tank loading and heating operations | |
Anti-corrosion heating resistors in INCOLOY 800 connected in switching to reduce electrical absorption. | |
Built-in stainless steel Boiler equipped with adjustable thermostat and safety thermostat to stop heating in case of lack of water | |
Entirely built in stainless steel 18/10 AISI 304 | |
Bath filter with microfilter on the pump aspiration to ensure perfect water filtration. | |
Non-return valve to prevent water spills in the water network. | |
Safety circuit breaker to prevent leakage of the detested water in case of opening of the loop door. | |
Volume rinse, not in time: the same volume of water is always used regardless of pressure variations to ensure water saving in case of unstable or too high water pressure. In case of little pressure, until the prefixed volume is reached, the rinsing is guaranteed |
- *BASKET
- *Square basket*
- *BASKET DIMENSIONS
- *Cm 40 x 40*
- *DRAIN PUMP
- *With drain pump*
- *COMMANDS
- *Electronic controls*
- *DISHWASHER TYPE
- *Frontal charge*
