Roller Grinder - Length cm 120 - Ø cm 25 - cm 141 x 39.5 x 107 h
G-PT-GI1225EVT
G-PT-GI1225EVT
€3,198.70
€3,476.85
-8%
€3,198.70 Senza tasse
€3,902.42 Con tasse
€3,476.85 Senza tasse
Tax excluded
Shipping times: from 3 days to 15 working days
Roller Grinder - Model GI1225 - Automatic conca movement - Productivity kg 37 - Length cm 120 - Diameter cm 25 - Three-phase - Dimensions cm 141 x 39.5 x 107 h
Stress | GI1225 |
Dimensions product | cm 141 x 39.5 x 107 h |
Dimensions packaging | C 152 x 53 x 131 h |
Net weight / Lord | Kg 89/106 |
Warranty | 12 months |
Norma | CE |
Origin | Italy |
TECHNICAL DATA | |
---|---|
Diameter of roller | mm 250 mm |
Length of roll | mm 1200 mm |
Productivity kg/h with UR% 10÷15% | 37 |
Internal coating | Steel wool |
External coating | Cotton cloth |
Contact surface | 0.264 m2 |
Conca Movement | Automatic |
ELECTRICAL DATA | |
---|---|
Power supply | Three-phase V380-415/3/50H |
Fuses | A 16-20 |
Power engine roller | kW 0.03 |
Power motor conca | Kw 0.05 |
Power total | Kw 6.08 |
Rumours | <60 dB |
GENERAL FEATURES | |
---|---|
Self-supporting structure made of grey plastic plate with small side shoulders for the advantage of the roller width useful for ironing operations | |
Automatic conca movement through new patented system free from maintenance and self-regulating | |
3 push elements placed behind the conca for uniformity of ironing quality throughout the roller | |
Aluminum conca treated with deep anodising guarantee of long life and energy saving | |
Heating elements positioned inside the aluminium rod for excellent heat transmission | |
Thermal insulation with thick ceramic wool | |
Roller supported by bearings and padded with triple layer of steel wool, cotton spring and outer cotton cloth | |
Single-front use with possibility of pulling the wall-mounted ironing machine | |
Wooden axis to facilitate the introduction of the linen with adjustable angle so as to adapt to the height of the operator | |
Wide upper part of the roller available to the operator to achieve a particularly useful introduction band effect in the case of large garments | |
Hand-saving device for operator protection in case of wrong maneuvers with forced air cooling system | |
Fox electronic control with temperature control with electronic thermostat | |
Control panel placed in such a way that you can easily manage the parameters with one finger and without moving from the workplace | |
Safety thermostat to prevent undesirable overheaving of manual rearmament | |
Mobile pedal for the control of the movement of the conca (opening/(a) where more frequent garments than standard should be introduced | |
Automatic device for removing the conca from the roller in case of lack of electricity that secures the machine and immediately allows to remove the head that was ironing |
